Iwaki Magnetic Pump Magnetic Drive Pumps MDW-100

Update Terakhir
:
27 / 02 / 2020
Min. Pembelian
:
1 Unit
Harga
CALL
PT. Surrama Tridaya Mandiri adalah perusahaan yang bergerak dalam bidang usaha importir , distributor alat-alat instrument : flowmeter, gas detector, control valve, safety valve, pressure reducing valve, dll

Detail Iwaki Magnetic Pump Magnetic Drive Pumps MDW-100

Features of MDW series

High discharge capacity, High head and high efficiency
The heavy-duty MDW is capable of a maximum discharge capacity of 300m³/hr and max. discharge head of 98m, enabling applications in previously unexplored areas with a wide range of liquid specific gravities.
Highly chemically resistant
Fluoroplastic and fine ceramic wetted parts offer high resistance to virtually every industrial chemical, irrespective of concentration.
Back pullout system
The back pullout system allows easy maintenance and inspection without removing pipework. Integrated components and a sealed rear casing support structure enable motor removal safely without chemical leakage.
ISO compliant
The MDW is dimensionally compliant with the international standard (ISO2858, 3661) and is interchangeable with conventional sealed centrifugal pumps.



Robust structure
Use of the high strength ductile cast iron external armour is mandatory for heavy duty chemical process applications. High casing pressure resistance is achieved with a unique rear casing design preventing stress concentration and incorporating a triple-layer structure (PAT.). A special metal shaft is used on the MDW to withstand high radial forces and allow continuous extended operation even under harsh service conditions.



Application example

  • Chemical transfer between supply tanks and through chemical process equipment.
  • Chemical recirculation for filtration and heat exchange applications.
  • Scrubber liquid recirculation.
  • Replacements for conventional sealed pumps.

Specifications (50/60Hz)

Max. discharge capacity range 800 – 5000 / 800 – 5000 L/min
Max. head range 22 – 98 / 32 – 98 m
Main materials MDW80/MDW100: ETFE, MDW50: PFA
Required power range 11 – 75 kW
Discharge bore 50 mm, 80 mm, 100 mm
Liquid temperature range MDW80/MDW100: −10 – 105˚C, MDW50: −10 – 120˚C
Sealing method Seal-less construction
